SAPPHIRE NITRO+ RADEON RX 590 8GD5 AMD 50TH GOLD ANNIVERSARY EDITION

SAPPHIRE NITRO+ RADEON RX 590 8GD5 AMD 50TH GOLD ANNIVERSARY EDITION

8,990.00 บาท

NITRO + RX 590 8GB AMD 50 Gold Edition

  • Engine Clock: Up to 1560 MHz (Boost)
  • Memory: 8GB GDDR5 8000 MHz Effective
  • 2304 Stream Processors
  • 1440p Gaming
  • Gold shroud
  • NITRO Glow, Quick Connect

Specifications

GPU

RX 590, 12 nm FinFET
4th Graphics Core Next (GCN)

Engine Clock

Up to 1560 MHz, Boost

Stream Processors

2304

Memory Size/Bus

8GB GDDR5/256-bit

Memory Clock

8000 MHz effective

Displays

Maximum 5 Outputs

Resolution

DisplayPort: 5120×2880@60Hz
HDMI: 4096×2160@60Hz
DVI:2560x1600@60Hz

Interface

PCI-Express 3.0

Output

  • 2x HDMI 2.0b
  • 2x DisplayPort 1.4
  • 1x DL-DVI-D

BIOS Support

  • Dual UEFI

API

  • OpenGL® 4.5
  • OpenCL 2.0
  • DirectX® 12
  • Shader Model 5.0

Game Index

1440p gaming

Sapphire Features

  • Gold shroud
  • White LED Fans
  • NITRO Fan Check
  • NITRO Quick Connect System
  • NITRO Glow RGB LED
  • NITRO CoolTech(NCT)
  • Intelligent Fan Control III
  • Precision Fan Control
  • Robust VRM Cooling
  • Black Diamond Choke 4
  • Long Life Polymer Capacitor
  • Fuse Protection
  • Dual UEFI



AMD Features

  • Radeon™ VR Ready Premium
  • Radeon™ Software
  • Radeon™ FreeSync Technology
  • AMD LiquidVR™ Technology
  • 4th Gen GCN Architecture
  • Radeon™ Chill
  • Radeon™ ReLive
  • DirectX® 12 Technology
  • AMD Eyefinity Technology (Gaming)
  • AMD App Acceleration
  • AMD CrossFire™ Technology
  • AMD CrossFire™ (Bridgeless)
  • 3rd Gen 14nm Process Technology
  • OpenCL 2.0
  • OpenGL 4.5
  • AMD PowerTune Technology
  • TrueAudio Next
  • Unified Video Decoder (UVD)
  • Video Code Engine (VCE)
  • Virtual Super Resolution
  • The Vulkan® API

Cooling

  • Dual-X fans
  • Two ball bearing

Form Factor

  • 2.2 Slots Occupied
  • 260X135X43 Dimension/mm

Power Consumption

  • <235W

OS

  • Windows®  10, Windows®  7
  • 64bit operating system required

System Requirement

  • 500 Watt Power Supply (Recommended)
  • 1 x 8-pin + 1 x 6-pin (optional) Power Connector
  • PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with
